Features
GERMAN ENGINEERING
Liebherr superior products offer premium quality, cutting edge design and innovative features that fit any busy lifestyle. Exclusive components and materials, along with the latest production processes, ensure energy efficiency and performance for years to come.
SOFTSYSTEM
Doors close automatically and gently thanks to the SoftSystem technology, which eliminates slamming even when shelves are fully loaded. Depending on which size Monolith
you choose, the door hinges are rated for up to 88 pounds.
SUPERQUIET
Noise levels are kept to a minimum thanks to virtually silent, speed-controlled, and sound-absorbing compressors. Alongside a low noise cooling circuit, these features ensure exact performance, energy efficiency, and SuperQuiet operation.
INFINITYSWIPE
Monolith’s intuitive electronic touch-control panel features a full-color 2.4-inch touch & swipe screen that’s bright, clean, and wonderfully user-friendly. You’ll barely have to lift a finger to control every function.
INFINITYLIGHT
Monolith’s seamlessly integrated LED side-wall lighting casts a beautiful and even glow that can be adjusted according to taste, including a soft brightening effect upon opening the doors, and a pleasing night dimming feature. InfinityLight doesn’t just add drama and flair, it also emits less heat, preserving food quality.
POWERCOOLING
Liebherr’s high-performance PowerCooling system ensures that newly stored foods are quickly cooled, while maintaining an even temperature throughout the interior. Taking this system one step further, Monolith circulates cold air behind the door, meaning that items stored in the door stay just as cold as everything else inside.
Specifications
General
Series Name
Monolith
Capacity
11.3 Cu. Ft.
Bottles
100
Number of Racks
9
Temperature Zones
3
Temperature Settings
+5 °C to +20 °C
Installation
Built-In
Type
Cooler
Size
Full Size
Color
Panel Ready
Manufacturer Color
Requires custom panel (sold separately)
Cabinet Color
Grey
Hinge
Right
Features
Technologies
• InfinitySwipe control
• InfinityLight
• InfinityProtection
• InfinityBoard
• InfinityLight
• InfinityProtection
• InfinityBoard
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Lock
No
Reversible Door
Yes
Additional Information
• 3,5" LCD color display, touch and swipe
• Noise level: 38 dB
• Malfunction warning signal: Optical and acoustical
• Door open warning signal, wine storage compartment: Audible
• Forced air cooling
• Activated charcoal filter
• Lighting: Illuminated side wall
• Light is dimmable
• Light can be switched on permanently
• Storage shelf material: Aluminium/Beech
• Noise level: 38 dB
• Malfunction warning signal: Optical and acoustical
• Door open warning signal, wine storage compartment: Audible
• Forced air cooling
• Activated charcoal filter
• Lighting: Illuminated side wall
• Light is dimmable
• Light can be switched on permanently
• Storage shelf material: Aluminium/Beech
Electrical Information
Information
• Voltage: 115 V
• Frequency: 60 Hz
• Connection rating: 3.0 A
• Energy consumption in 24h: 0.465 kWh / 24h
• Energy consumption per year: 170 kWh/a
• Frequency: 60 Hz
• Connection rating: 3.0 A
• Energy consumption in 24h: 0.465 kWh / 24h
• Energy consumption per year: 170 kWh/a
Accessories
Optional
• 9901 533: Stainless steel door panel wine 24"
• 9901 461: Monolith brushed aluminum square handle
• 9901 489: Monolith stainless steel round handle
• 9901 492: Monolith brushed aluminum soft-edge handle
• 9901 496: Stainless steel Toe Kick 24"
• 9096 342: FreshAir activated charcoal filter
• 9902 399: Reverse door kit
• 9901 428: Side-by-Side kit (includes wall heater)
• 9901 461: Monolith brushed aluminum square handle
• 9901 489: Monolith stainless steel round handle
• 9901 492: Monolith brushed aluminum soft-edge handle
• 9901 496: Stainless steel Toe Kick 24"
• 9096 342: FreshAir activated charcoal filter
• 9902 399: Reverse door kit
• 9901 428: Side-by-Side kit (includes wall heater)
Dimensions
Width
23.7 inch(es) / 60.2 cm
Height
83.7 inch(es) / 212.6 cm
Depth (Without Handle)
24.02 inch(es) / 61.0 cm
Weight
354.94 lb(s) / 161 kg
Shipping Dimensions
Width
26.18 inch(es) / 66.5 cm
Height
89.37 inch(es) / 227 cm
Depth
30.12 inch(es) / 76.5 cm
Weight
381.4 lb(s) / 173 kg
Warranty
Warranty
• Full 2-Year Warranty
• Full 5-Year Warranty in the Sealed System
• Limited 6 to 12-Year Warranty
• Full 5-Year Warranty in the Sealed System
• Limited 6 to 12-Year Warranty
