Features
TWO TEMPERATURE-CONTROLLED ZONES (FOR WINE CELLAR)
Allows for two temperature zones to chill both whites and reds at their optimal temperatures to help preserve the flavor and integrity of individual wines. The top zone adjusts from 42-54°F for whites while the lower zone can be set from 42-64°F for reds.
UV-PROTECTED THERMAL GLASS DOOR
Filters UV rays to help protect wine and other beverages from premature aging.
DOOR ALARM
Automatically alerts you when the door has been left open before items inside rise above their ideal temperature. The alarm sounds after fives minutes and goes off every two minutes until the door has been closed or the controls have been pressed.
FULLY FLUSH INSTALLATION WITH HIDDEN HINGES
Provides a built-in look within a standard 24" base cabinet, so your style stands out, not the appliance. Hidden hinges allow the beverage center door to sit flush with surrounding cabinet fronts when closed yet easily swing open a full 90 degrees.
TEMPERATURE MONITORING SYSTEM
Uses sensors to monitor temperatures inside the wine cellar for added peace of mind. If the system detects temperatures above 70°F for more than 4 hours, an over-temp alarm and indicator light will alert you that service is needed.
MOTION-ACTIVATED LED LIGHTING
Turns on inside as you approach, so you can see what's inside without opening the door. Lights will gradually dim and turn off when no longer needed.
Specifications
General
Capacity
4.97 Cu. Ft.
Bottles
46
Number of Racks
6
Temperature Zones
2
Temperature Settings
• Upper Zone Temperature Range: 42F to 54F
• Lower Zone Temperature Range: 42F to 64F
• Lower Zone Temperature Range: 42F to 64F
Installation
Built-In
Type
Cellar
Size
Compact
Color
Panel Ready
Manufacturer Color
• Panel Ready
• Custom panel required (sold separately)
• Custom panel required (sold separately)
Cabinet Color
Black
Hinge
Right
Features
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Reversible Door
No
Additional Information
• Auto Defrost
• Control Type: Light-Guided Capacitive Touch
• Cooling On/Off
• Door Ajar/Open Alarm
• Control Lockout
• Reach-Through Handle
• LED Interior Light
• Rack Front Material: Wood
• Control Type: Light-Guided Capacitive Touch
• Cooling On/Off
• Door Ajar/Open Alarm
• Control Lockout
• Reach-Through Handle
• LED Interior Light
• Rack Front Material: Wood
Electrical Information
Information
• Amps: 15
• Volts: 115
• Volts: 115
Certifications and Approvals
Energy Star Certified
No
Sabbath/Star-K
Yes
Dimensions
Width
23.87 inch(es) / 60.64 cm
Height
34.37 inch(es) / 87.31 cm
Depth (Without Handle)
23.63 inch(es) / 60.01 cm
Weight
128.4 lb(s) / 58.24 kg
Additional Dimensions
• Depth With Door Open 90 Degree: 48"
• Cutout Depth: 24"
• Cutout Height: 34 1/2"
• Cutout Width: 24
• Cutout Depth: 24"
• Cutout Height: 34 1/2"
• Cutout Width: 24
Shipping Dimensions
Width
25.75 inch(es) / 65.41 cm
Height
35.94 inch(es) / 91.28 cm
Depth
29.69 inch(es) / 75.41 cm
Weight
139 lb(s) / 63.05 kg
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
883049592862
