Features
JX3™ DOWNDRAFT VENTILATION SYSTEM WITH 3-SPEED FAN
The powerful JX3™ downdraft uses proximity ventilation to capture smoke and cooking odors right at the cooking surface, to powerfully clear the air without requiring a hood.
17,000 BTU ULTRA-HIGH OUTPUT BURNER
Enjoy the robust heat necessary for high-powered cooking techniques, whether searing a steak, stir-frying vegetables or rapidly boiling water.
DURAFINISH™ PROTECTION
With excellence in every detail, DuraFinish® Protection helps keep your cooktop’s surface looking like new, resisting yellowing, staining and scratching.
CONVERTIBLE TO LP
This rangetop allows you to easily adapt your energy source from natural gas to propane.
BRASS BURNERS WITH REMOVABLE BASE
Elegant brass burners effectively direct heat for desired cooking results and can be removed for easy cleaning.
CONVERTIBLE TO DUCT-FREE VENTILATION
Keep the view from your kitchen open and free from ductwork with this optional kit that allows conversion to duct-free ventilation.
Specifications
General
Color
Black
Manufacturer Color
Black
Fuel Type
Natural Gas
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Left Front Element-Burner Power: 17,000 BTU
• Left Rear Element-Burner Power: 5,000 BTU
• Right Front Element-Burner Power: 10,000 BTU
• Right Rear Element-Burner Power: 15,000 BTU
• Left Rear Element-Burner Power: 5,000 BTU
• Right Front Element-Burner Power: 10,000 BTU
• Right Rear Element-Burner Power: 15,000 BTU
Burners
Sealed
Surface Features
Porcelain Coated Steel
Features
Technologies
• JX3™ Downdraft Ventilation System with 3 Speeds
• DuraFinish® Protection
• DuraFinish® Protection
Downdraft Ventilation
Yes
Additional Information
• Brass Burners with Removable Base
• Convertible to Duct-Free Ventilation
• CFM Rating: 310
• Dishwasher Safe
• Convertible to Duct-Free Ventilation
• CFM Rating: 310
• Dishwasher Safe
Electrical Information
Information
• 120 V
• 40 A
• 60 Hz
• 40 A
• 60 Hz
Certifications and Approvals
ADA Compliant
Yes
Accessories
Included
• LP Convertible Kit
• Power Cord
• Power Cord
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
4 inch(es) / 10.16 cm
Depth
21.5 inch(es) / 54.61 cm
Weight
46.01 lb(s) / 20.87 kg
Additional Dimensions
• Cutout Depth: 19 15/16"
• Cutout Height: 4"
• Cutout Width: 28 5/8"
• Cutout Height: 4"
• Cutout Width: 28 5/8"
Shipping Dimensions
Width
35.13 inch(es) / 89.22 cm
Height
23.81 inch(es) / 60.48 cm
Depth
26.44 inch(es) / 67.15 cm
Weight
58 lb(s) / 26.31 kg
Warranty
Warranty
Limited 2 Years Parts and Labor
UPC
UPC#
883049414454
